Mosaic Hammam

The Mosaic Hammam, or Turkish bath is a product thoughtfully designed and manufactured by Issgard. It represents a hybrid model between prefabricated cabins and custom-built Turkish baths. This equipment aims to enhance and combine the immersive experience of well-being and relaxation offered by custom-built hammams with the advantages of installation and cost efficiency associated with prefabricated cabins.

The materials used, including extruded polystyrene and fiber cement finishes, allow for ceramic cladding, where the color and texture will contribute to the bespoke design that the client expects. We customize the vaulted ceiling using methyl methacrylate to prevent water droplets and promote responsible water consumption by reducing usage.

As part of our manufacturing and customization process for Turkish baths or hammams, we can supply them without cladding for clients to decorate and tile themselves, ensuring total integration into their space and creating an even more immersive and unique user experience.

Nos Projets

Technical features

Materials

  • Wall Modules:

Made from polyester fiber panel over an anodized aluminum structure reinforced with polyester resin and multilayer.

  • Ceiling Modules:

Made from 3 mm acrylic panel over an anodized aluminum structure reinforced with polyester resin and multilayer              with a vaulted shape.

  • Interior Cladding:

Large-format porcelain coating (various colors available).

  • Interior Elements:

Bench made from polyester resin.
Trim and probe in anodized aluminum.
Diffuser in stainless steel.
White light fixture.

  • Bottom and Top Ring:

Anodized aluminum

  • Handle:

Stainless steel tubular

  • Front:

Laminated glass (5+5) of 10 mm

  • Door:

8 mm tempered glass, anodized aluminum hinges
Passage of 55 cm
*Can vary according to custom design

Electrical systems

  • Lighting:

    LED Spotlights / White LED 12V
  • Control Panel:

    Ecotouch
  • Heater:

    Depending on the model
  • Connection:

    Silicone wiring
    400 V III + Neutral + Ground
    230 V III + Neutral + Ground
    230 V I + Neutral (Max 9 Kw)
